Silverstone presenta Olympia il suo nuovo alimentatore
The Olympia series continues the fine form established by the first SilverStone performance single +12V rail Zeus ST56ZF and expands to a new plateau. Precision manufactured by industry leading robotics assembly line and designed by SilverStone’s world-class PSU engineering team, the Olympia OP650 possess serious performance with real-world usability. With a single +12V rail continuous output up to 54A at 50°C, this peerless power is harnessed in a compact enclosure that is cooled by SilverStone’s high quality 9-bladed 120mm fan, the FM121, and tuned to perfection.
Combining these performance and ergonomic attributes into a power supply such as the OP650 is a dream come true not only for ardent enthusiasts but also for those who are simply looking for the best.
|
Max. DC Output |
650W |
|||||||||||||||||||||||||||||||||||||||||||||||||
|
Load Range |
||||||||||||||||||||||||||||||||||||||||||||||||||
|
||||||||||||||||||||||||||||||||||||||||||||||||||
|
combined+3.3 , +5V |
180W |
|||||||||||||||||||||||||||||||||||||||||||||||||
|
combined +3.3V, +5V, +12V |
630W |
|||||||||||||||||||||||||||||||||||||||||||||||||
|
Input Voltage |
90V ~ 264V (Auto Range) |
|||||||||||||||||||||||||||||||||||||||||||||||||
|
Input Frequency Range |
47Hz ~ 63Hz |
|
PFC |
Active PFC (PF>0.99 at full load) |
|
Efficiency |
>80% |
|
MTBF |
100,000 hours at 25°C, full load |
|
Operating temperature |
0 ~ 50°C |
|
Protection |
Over current protection, Over power protection, Over voltage protection, Short circuit protection |
|
Connectors |
1 x 24/20-pin motherboard connector (550mm) |
|
1 x 8/4-pin ATX12V connector (550mm) |
|
|
1 x 6-pin AUX connector (550mm) |
|
|
1 x 8-pin PCI-E connector (550mm) |
|
|
2 x 6-pin PCI-E connector (550mm) |
|
|
2 x triple SATA power connectors (500mm + 250mm + 250mm) |
|
|
2 x triple 4-pin IDE
& single floppy power connectors |
|
|
Color |
black (lead-free paint) |
|
Cooling System |
Single 120mm ball bearing fan |
|
Noise Level |
22 dBA minimum |
|
Weight |
2.6 kg |
|
Dimension |
150 mm (W) x 86 mm (H) x 150 mm (D) |
